LiFePO4 51.2V Wall Mounted Battery Series
LiFePO4 51.2V Wall Mounted Battery Series (50Ah~314Ah), elegant wall-mount design, smart BMS, up to 16 units in parallel. 5-year warranty.
Reference price: $1199.00 USDPre-order
Stock: confirmed by orderFor households, installers, dealers, hotels, villas, and factories.
Battery, inverter, PV panel, and accessory availability is confirmed within 24h by city, quantity, and project configuration.
الضمان 5 years
شحن عالمي
أصلي 100%
المميزات الرئيسية
- Elegant wall-mounted design saves floor space
- High voltage 51.2V for superior efficiency
- Smart BMS with comprehensive protection
- Multi-inverter compatible (PYLON, DEYE, GROWATT...)
- Up to 16 units in parallel for flexible expansion
المواصفات الفنية
| 50Ah | 100Ah | 200Ah | 314Ah | |
|---|---|---|---|---|
| Capacity | 50Ah / 2560Wh | 100Ah / 5120Wh | 200Ah / 10240Wh | 314Ah / 16077Wh |
| Charge/Discharge Current | 5A ~ 50A | 10A ~ 100A | 20A ~ 200A | 30A ~ 200A |
| Dimensions (W×D×H) | 270×160×360 mm | 390×190×630 mm | 390×230×620 mm | 390×230×670 mm |
| Weight | 29 kg | 46.5 kg | 87.5 kg | 127 kg |
| Nominal Voltage | 51.2V | 51.2V | 51.2V | 51.2V |
| Chemistry | LiFePO4 | LiFePO4 | LiFePO4 | LiFePO4 |
| Max Charge Voltage | 58.4V | 58.4V | 58.4V | 58.4V |
| Min Discharge Voltage | 40V | 40V | 40V | 40V |
| Operating Temperature | -20°C ~ 60°C | -20°C ~ 60°C | -20°C ~ 60°C | -20°C ~ 60°C |
| BMS | Charge/Discharge/Short/Temp/Balance Protection | Charge/Discharge/Short/Temp/Balance Protection | Charge/Discharge/Short/Temp/Balance Protection | Charge/Discharge/Short/Temp/Balance Protection |
| Communication | RS485, RS232, CAN | RS485, RS232, CAN | RS485, RS232, CAN | RS485, RS232, CAN |
| Inverter Compatibility | PYLON, DEYE, GROWATT, GOODWE, SOLAX, LUXPOWER, MUST, SRNE, MEGAREVO | PYLON, DEYE, GROWATT, GOODWE, SOLAX, LUXPOWER, MUST, SRNE, MEGAREVO | PYLON, DEYE, GROWATT, GOODWE, SOLAX, LUXPOWER, MUST, SRNE, MEGAREVO | PYLON, DEYE, GROWATT, GOODWE, SOLAX, LUXPOWER, MUST, SRNE, MEGAREVO |
| Max Parallel | 16 units | 16 units | 16 units | 16 units |
| Certification | CE, RoHS | CE, RoHS | CE, RoHS | CE, RoHS |
| Warranty | 5 years | 5 years | 5 years | 5 years |
استشارة مجانية عبر واتساب
الرد خلال 5 دقائق
الأسئلة الشائعة
ما هي مدة ضمان LiFePO4 51.2V Wall Mounted Battery Series؟▼
يأتي LiFePO4 51.2V Wall Mounted Battery Series بضمان 5 years من Batelithium. نقدم دعمًا فنيًا كاملاً طوال فترة الضمان.
هل تشحنون دولياً؟▼
تشحن Batelithium إلى جميع أنحاء العالم. شحن مجاني للطلبات بالجملة. تواصل معنا للحصول على عرض سعر مخصص.
